Catalog 2021
VEKPANEL SA
dali switch-dim - emergency sensor RoHS CE Insulation - ip40 ip54 Tunable White

Specifications

  • Fabricated steel body with electrostatic powder coated
  • PS opal diffuser
  • PMMA and Prismatic diffuser options
  • 220-240V, 50-60 Hz
  • Operating Temperature (Ta): -200C / +350C

Application

  • Offices
  • Educational Facilities
  • Retails
  • Hospital and wellness
Watt Lumen lm/W CRI Kelvin (K) Dimension Code
11 968 88+ 80+ 2700~6500 300x300mm 15411001-070035
19 2090 110+ 80+ 2700~6500 300x600mm 15411003-071035
21 2688 128+ 80+ 2700~6500 600x600mm 15411002-072035
28 3584 128+ 80+ 2700~6500 600x600mm 15411002-073035
32 4096 128+ 80+ 2700~6500 600x600mm 15411002-074035
37 4736 128+ 80+ 2700~6500 600x600mm 15411002-075035
37 4736 128+ 80+ 2700~6500 300x1200mm 15411004-075035
75 8775 117+ 80+ 2700~6500 600x1200mm 15411005-076035

The lumen values are only for reference. There may be changes in the data according to LED chip and driver.

vekpanel-tdw
vekpanel-ph

White

Black

Grey
