TRIGON RING 80 T UP&DOWN
- - - - - - - - - - - -

Specifications

  • Electrostatic powder coated aluminium extruded body with fabricated steel back cover
  • PMMA opal diffuser, Prismatic diffusers as an option
  • LED (L80/B10) + DRIVER life time more than 50.000 Hours
  • Midpower LED light source
  • Input Voltage: 220-240V, 50-60 Hz
  • Operating Temperature (Ta): -200C / +350C

Application

  • Offices
  • Educational Facilities
  • Shops and Stores
  • Architectural Applications
Watt Lumen lm/W CRI Kelvin (K) Dimension Code
64 (down)
27 (up)		 6650 (down)
3070 (up)		 100+ (down)
110+ (up)		 80+ 2700~6500 L: 3x900mm 2581060201-0703003051
82 (down)
35 (up)		 8520 (down)
3990 (up)		 100+ (down)
110+ (up)		 80+ 2700~6500 L: 3x1200mm 2581060202-0704003051

The lumen values are only for reference. There may be changes in the data.

trigon80shape-t-udt-tech
-

WHITE

GREY

BLACK

All RAL colours available as an option.
