Catalog 2023
MERCURY H5 ROYAL SU
- - - - - - - - - - - - - -

Specifications

  • Recessed body: Electrostatic powder coated die cast aluminium
  • Surface mounted: Recessed body + fabricated steel cover with
    electrostatic powder coated
  • Clear PMMA cover or tempered glass cover
  • 99,9% pure aluminium reflector
  • 3-step Mac Adam color consistency
  • Input Voltage: 220-240V, 50-60 Hz
  • Operating Temperature (Ta): -200C/+350C


Application

  • Offices
  • Educational Facilities
  • Retails
  • Hospitals
Watt Lumen lm/W CRI Kelvin (K) Dimension Code
19 961 51+ 80+ 2700~6500 W:165mm 02213101-330035
26 1376 53+ 80+ 2700~6500 W:165mm 02213101-331035
32 1638 51+ 80+ 2700~6500 W:165mm 02213101-332035
42 1927 46+ 80+ 2700~6500 W:165mm 02213101-333035

The lumen values are only for reference. There may be changes in the data according to LED chip and driver.

-
-
All RAL colours available as an option.
