Catalog 2023
ACOUSTIC FLOW LINE T
- - - - - - - - - - - - - - - -

Specifications

  • Decorative acoustic luminaire with 1800 g PET felt body made from recycled plastic bottle fibers
  • Soft acoustic felt surface on both exterior and interior sides
  • Electrostatic powder coated aluminium body with fabricated steel back cover
  • PMMA opal diffuser; prismatic diffuser available as an option
  • Mid-power LED light source
  • LED L80/B10 and driver lifetime over 100,000 hours
  • Input voltage: 220–240V, 50–60 Hz
  • Operating temperature Ta: -20°C / +35°C
  • CASAMBI, EasyAir Sensor, DALI Sensor and other control options        available upon request

Application

  • Offices
  • Educational Facilities
  • Shops and stores
  • Architectural Applications
Watt Lumen lm/W CRI Kelvin (K) Dimension Code
15 1700 113+ 80+ 2700 ~ 6500 L: 600mm 6982060201-0501003051
20 2270 113+ 80+ 2700 ~ 6500 L: 900mm 6982060202-0502003051
27 3060 113+ 80+ 2700 ~ 6500 L: 1200mm 6982060203-0503003051
34 3850 113+ 80+ 2700 ~ 6500 L: 1500mm 6982060204-0504003051
19 2150 113+ 80+ 2700 ~ 6500 L: 600mm 6982060201-0505003051
30 3400 113+ 80+ 2700 ~ 6500 L: 900mm 6982060202-0506003051
40 4550 113+ 80+ 2700 ~ 6500 L: 1200mm 6982060203-0507003051
51 5800 113+ 80+ 2700 ~ 6500 L: 1500mm 6982060204-0508003051

The lumen values are only for reference. There may be changes in the data according to LED chip and driver.

-
-
All RAL colours available as an option.
