MERCURY K S5 SA | Vekta Aydınlatma ve Teknoloji A.Ş.

Recessed body: Electrostatic powder coated die cast aluminium
Surface mounted: Recessed body + fabricated steel cover with electrostatic powder coated
Clear PMMA cover. Tempered glass cover option
COB LED light source
LED (L80/B10) + DRIVER life time more than 50.000 Hours
%99,9 pure aluminium reflector
Input Voltage: 220-240V, 50-60 Hz
Operating Temperature (Ta): -20⁰C/+35⁰C

Watt	Lumen	lm/W	CRI	Kelvin (K)	Dimension	Code
19	1634	86+	80+	2700~6500	150x150mm H:100mm	0251021801-3301003051
26	2340	90+	80+	2700~6500	150x150mm H:100mm	0251021801-3302003051
*32	2784	87+	80+	2700~6500	150x150mm H:100mm	0251021801-3303003051
42	3276	78+	80+	2700~6500	150x150mm H:100mm	0251021801-3304003051

Watt

Lumen

lm/W

CRI

Kelvin (K)

Dimension

Code

1634

86+

80+

2700~6500

150x150mm H:100mm

0251021801-3301003051

2340

90+

80+

2700~6500

150x150mm H:100mm

0251021801-3302003051

*32

2784

87+

80+

2700~6500

150x150mm H:100mm

0251021801-3303003051

3276

78+

80+

2700~6500

150x150mm H:100mm

0251021801-3304003051

The lumen values are only for reference. There may be changes in the data according to LED chip and driver.
